MAINLY USED IN
OPERATING WEIGHT
50,800 kg
BUCKET CAPACITY (SAE HEAPED)
2.7 m³
ENGINE POWER (SAE J1349, NET)
257 kW @ 1,800 rpm
ENGINE
With more potent engine with 14% additional power, careful control over enhanced energy efficiency has led to superior product quality and durability; thus improving parts versatility and compatibility. Moreover, the engine meets the tier-2 automobile emission standards as well as requirements for energy conservation and environmental protection.
HYDRAULIC SYSTEM
The state-of-the-art VBO hydraulic system electronically regulates the accuracy and responsiveness of the main pump, increasing the flow rate and reducing energy consumption by interrupting flow when needed.
FUEL CONSUMPTION
Adopting a low-fuel consumption design, the DX490LCA-7B and DX530LCA-7B incorporate fuel-saving control technology known as SPC3 (Smart Power Control); thus achieving fuel efficiency surpassing that of the 7B Series.
| Classification | DX490LCA-7B |
|---|---|
| Operating Weight | 50,800 kg |
| Bucket Capacity (SAE HEAPED) | 2.7 m³ |
| Engine Power (SAE j1349, net) | 257 kW @ 1,800 rpm |
| Engine Model | DX12 |
| Travel Speed | 5.5 / 3.1 km/h |
| Max. Digging Reach | 12,115 mm |
| Max. Digging Depth | 7,770 mm |
| Max. Digging Height | 11,020 mm |
| Overall Length | 12,220 mm |
| Overall Width | 3,340 ~ 3,900 mm |
| Overall Height | 3,370 mm |

                | Classification |
|---|
| Operating Weight |
| Bucket Capacity (SAE HEAPED) |
| Engine Power (SAE j1349, net) |
| Engine Model |
| Travel Speed |
| Max. Digging Reach |
| Max. Digging Depth |
| Max. Digging Height |
| Overall Length |
| Overall Width |
| Overall Height |
| DX490LCA-7B |
|---|
| 50,800 kg |
| 2.7 m³ |
| 257 kW @ 1,800 rpm |
| DX12 |
| 5.5 / 3.1 km/h |
| 12,115 mm |
| 7,770 mm |
| 11,020 mm |
| 12,220 mm |
| 3,340 ~ 3,900 mm |
| 3,370 mm |
